How does the trommel screen work?
Trommel screen is a common screening equipment, widely used in mining, building materials, chemical industry and other industries. Its working principle is based on the rotational movement of materials in the drum, and the separation of materials with different particle sizes is achieved through the screen holes. The following is the detailed working principle and structural analysis of the trommel screen.
1. Basic structure of trommel screen
The drum screen mainly consists of the following parts:
| Component name | Function description |
|---|---|
| roller | It is composed of screen mesh or sieve plate and is responsible for screening materials. |
| Drive unit | Provides power to rotate the drum. |
| Bracket | Support the roller to ensure stable operation of the equipment. |
| Feed port | The material enters the entrance of the drum. |
| Discharge port | The screened material is exported. |
2. Working principle of trommel screen
The working principle of the trommel screen can be divided into the following steps:
1.Feed: Material enters the inside of the drum through the feed port.
2.Rotary screening: The drum rotates driven by the driving device, and the material continuously rolls inside the drum.
3.screening process: Materials smaller than the screen hole size fall through the screen hole, and materials larger than the screen hole size continue to move forward.
4.Discharge: The screened materials are discharged from different discharge ports.
3. Working characteristics of trommel screen
| Features | describe |
|---|---|
| Efficient screening | The rotating motion of the drum screen fully disperses the materials and improves screening efficiency. |
| Simple structure | The trommel screen has a simple structure and is easy to maintain and operate. |
| Adaptable | It is suitable for screening a variety of materials, such as ore, coal, sand and gravel, etc. |
| low noise | The trommel screen runs smoothly and has low noise. |
4. Application fields of trommel screen
Trommel screens are widely used in the following fields:
1.Mining industry: Used for screening and grading of ores.
2.Building materials industry: Used for screening sand, gravel, cement and other materials.
3.Chemical industry: Used for screening and classifying chemical raw materials.
4.Environmental protection industry: Used for screening work in garbage disposal.
5. Maintenance and maintenance of trommel screen
In order to ensure the normal operation of the trommel screen, regular maintenance and upkeep are required:
1.Regular inspection: Check whether the screen is damaged and replace it in time.
2.lubricating: Lubricate the driving device regularly to reduce wear.
3.clean: Clean the remaining materials in the drum to avoid clogging.
6. Suggestions for purchasing trommel screen
When purchasing a trommel screen, you need to consider the following factors:
| factor | suggestion |
|---|---|
| Material properties | Select the appropriate screen mesh according to the particle size, humidity, etc. of the material. |
| Throughput | Select the appropriate size trommel screen according to production needs. |
| Equipment material | Choose wear-resistant and corrosion-resistant materials to extend service life. |
| Brand reputation | Choose well-known brands to ensure equipment quality and after-sales service. |
Summarize
The trommel screen is a kind of efficient and simple structure screening equipment, which is widely used in many industries. Its working principle is based on the rotational screening of materials, and the separation of materials with different particle sizes is achieved through the sieve holes. Understanding the structure, working principle and maintenance methods of the trommel screen will help improve the service life and production efficiency of the equipment. When purchasing a trommel screen, you need to comprehensively consider factors such as material characteristics and processing capacity to select suitable equipment.
